Pipe Fiber Laser Cutting Machine Offside Zero Tail

Core Technology: Offside Zero Tail Advantage

The revolutionary Offside Zero Tail design breaks through the limitation of traditional cutting machines that leave residual tail materials. By optimizing the laser head trajectory and clamping mechanism, our machine achieves zero tailing cutting for pipes of various specifications. Whether processing carbon steel, stainless steel, aluminum alloy, or copper tubes, it ensures that almost 100% of the raw material is utilized, significantly reducing material costs for your production line—especially critical for high-value metal pipes.

Superior Cutting Performance

1.High-Power Fiber Laser Source: Equipped with a top-tier fiber laser (available in 1000W/1500W/2000W/3000W options), the machine delivers fast cutting speed (up to 60m/min for thin-walled tubes) and smooth cutting edges with Ra ≤ 1.6μm, eliminating the need for secondary finishing.

2.Wide Processing Range: Capable of handling round pipes (φ20-200mm), square pipes (20×20-180×180mm), rectangular pipes (20×40-160×200mm), and special-shaped pipes. The maximum pipe length can reach 6000mm, adapting to diverse production needs.

3.Precision Positioning System: Adopts high-precision ball screws and servo motors, ensuring a positioning accuracy of ±0.03mm/m and repeatability of ±0.02mm. The Offside Zero Tail structure further enhances cutting precision at the pipe end, avoiding material waste caused by inaccurate tail cutting.

Intelligent & User-Friendly Design

1.Advanced Control System: Integrated with a industrial-grade CNC system and a 15-inch touchscreen, it supports automatic nesting, parameter memory, and fault self-diagnosis. The intuitive interface allows operators to master operation quickly, reducing training costs.

2.Efficient Clamping & Feeding: The multi-point pneumatic clamping system provides stable grip without damaging the pipe surface. The automatic feeding mechanism realizes continuous processing of multiple pipes, improving production efficiency by 30% compared to traditional machines.

3.Safety & Environmental Protection: Equipped with a full-enclosed protective cover, laser safety interlock, and smoke dust collection system, it meets international safety standards (CE/FDA) and creates a clean working environment.

FAQ

How To Use The Machine After Receving The Machine？

Firstly , when you got machine , you need to contact with us ,our engineer will together with your to deal with it ,secondly ,we will send you user manual or videos before you get the machine ,Thirdly Our professional technician online teach you until you can use it well by yourself.

Why Should You Buy From Us Not From Other Suppliers?

We are professional equipment manufacturer, Our service as below: 1. Factory supply directly 2. 12 months warranty for the whole machine 3. Friendly English version manual and operation video 5. Engineer available to service machinery overs.

What Services Can We Provide?

Accepted Delivery Terms: FOB,CFR,CIF,EXW； Accepted Payment Currency:USD,EUR,CNY.

How To Choose A Suitable Machine?

You can tell us the working piece material, size, and the request of machine function. We can recommend the most suitable machine according to our experience. It can be customized according to your requirements.

Do You Have A Setup And Equipment Commissioning Service?

Yes,we have. The machine was installed and debugged before delivery. You can use the machine directly after receiving it. Of course, we also could let our technologists go to your country to install and debug.
