Big pipe CNC Fiber tube laser cutting machine
Big Pipe CNC Fiber Tube Laser Cutter. Built for large-diameter pipes, with fiber laser precision and CNC stability. Cuts thick, big pipes smoothly and efficiently—perfect for industrial-scale big pipe cutting needs.
Brand：Gain
Product origin：Weifang,Shandong,China
Delivery time：7-30 days
Supply capacity：500 units/year
Send Inquiry
Product Description
Core Strength: Unmatched Big Pipe Processing Capacity
1.Wide Diameter Coverage: Capable of handling round pipes from φ200mm to φ800mm, square pipes up to 600×600mm, and rectangular pipes up to 500×700mm—accommodating the most demanding big-pipe requirements in industrial manufacturing.
2.Thick-Wall Cutting Prowess: Equipped with high-power fiber laser sources (3000W-12000W options), it effortlessly cuts through pipes with wall thicknesses up to 30mm (for carbon steel) and 20mm (for stainless steel), delivering clean, burr-free edges without secondary processing.
3.Long Pipe Adaptability: Supports pipe lengths up to 12000mm, with an optional extended bed available for 18000mm pipes, making it ideal for large-scale projects like oil and gas pipelines, structural steel components, and heavy machinery parts.
Stable & Precise: Built for Heavy-Duty Performance
1.Rigid Machine Bed: The one-piece welded bed undergoes multiple aging treatments (vibration aging + natural aging) to eliminate internal stress, ensuring minimal deformation even under the weight of 1000kg+ pipes. This foundational stability guarantees consistent cutting accuracy.
2.Dual-Drive Clamping System: Adopts a 4-jaw hydraulic chuck (front) and 3-jaw pneumatic chuck (rear) with adjustable clamping force, providing firm grip on large pipes without damaging surfaces. The synchronized chuck operation eliminates pipe deflection during high-speed rotation (up to 30rpm).
3.High-Precision Motion Control: Integrated with imported servo motors and high-precision ball screws, the machine achieves a positioning accuracy of ±0.03mm/m and repeatability of ±0.02mm. The laser head’s 3-axis linkage system ensures precise tracking of complex contours on large pipe surfaces.
FAQ
How To Use The Machine After Receving The Machine？
Firstly , when you got machine , you need to contact with us ,our engineer will together with your to deal with it ,secondly ,we will send you user manual or videos before you get the machine ,Thirdly Our professional technician online teach you until you can use it well by yourself.
Why Should You Buy From Us Not From Other Suppliers?
We are professional equipment manufacturer, Our service as below: 1. Factory supply directly 2. 12 months warranty for the whole machine 3. Friendly English version manual and operation video 5. Engineer available to service machinery overs.
What Services Can We Provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW； Accepted Payment Currency:USD,EUR,CNY.
How To Choose A Suitable Machine?
You can tell us the working piece material, size, and the request of machine function. We can recommend the most suitable machine according to our experience. It can be customized according to your requirements.
Do You Have A Setup And Equipment Commissioning Service?
Yes,we have. The machine was installed and debugged before delivery. You can use the machine directly after receiving it. Of course, we also could let our technologists go to your country to install and debug.
