High speed dual pallet laser cutting machine for industrial use
The High-Speed Dual Pallet Laser Cutting Machine for Industrial Use is a next-generation solution designed to meet the demands of high-volume, high-precision metal cutting in modern manufacturing.
Brand：Gain
Product origin：Weifang,Shandong,China
Delivery time：7-30 days
Supply capacity：500 units/year
Send Inquiry
Product Description
High-Speed Dual Pallet Laser Cutting Machine for Industrial Use
Continuous, High-Efficiency Cutting Solution for Large-Scale Metal Fabrication
The High-Speed Dual Pallet Laser Cutting Machine for Industrial Use is a next-generation solution designed to meet the demands of high-volume, high-precision metal cutting in modern manufacturing. With a dual pallet (exchange table) design, it maximizes productivity by allowing simultaneous cutting and material loading/unloading, minimizing downtime and significantly boosting output.
Equipped with a high-power fiber laser source, advanced CNC control system, and precision motion technology, this machine delivers exceptional cutting speed, superior edge quality, and reliable performance — even in continuous 24/7 industrial production environments. It’s the ideal choice for manufacturers in automotive, aerospace, construction, machinery, and sheet metal processing industries.
Key Features
Dual Pallet Exchange System for Maximum Productivity
While one pallet is cutting, the other is used for loading or unloading materials. This reduces idle time and improves production efficiency by up to 60%.
High Cutting Speed & Precision
Equipped with a high-power fiber laser source (3kW – 30kW) and precision servo system, achieving cutting speeds of up to 140 m/min with accuracy of ±0.03 mm.
Industrial-Grade Stability & Durability
Heavy-duty welded machine frame, high-strength gantry structure, and advanced drive system ensure long-term reliability and precise performance.
Smart CNC Control System
Intelligent software supports automatic nesting, real-time monitoring, path optimization, and remote control, making operation efficient and user-friendly.
Wide Material Compatibility
Efficiently cuts carbon steel, stainless steel, aluminum, brass, copper, galvanized steel, and alloy materials with smooth, burr-free edges.
Energy Efficient & Low Maintenance
Fiber laser technology offers high energy conversion efficiency, low running costs, and long service life — typically over 100,000 hours.
Technical Specifications
| Parameter | Value |
| Laser Power | 3000W – 30000W |
| Working Area | 3000 × 1500 mm / 4000 × 2000 mm (customizable) |
| Pallet System | Dual exchange table (automatic) |
| Positioning Accuracy | ±0.03 mm |
| Repeatability | ±0.02 mm |
| Max Cutting Speed | Up to 140 m/min |
| Supported Materials | Carbon steel, stainless steel, aluminum, copper, galvanized steel, brass, alloy steel |
| Max Cutting Thickness | Up to 50 mm (depending on power and material) |
| Cooling System | Industrial water cooling |
| Assist Gas | Oxygen, nitrogen, air |
Applications
Automotive components and chassis manufacturing
Aerospace and aviation parts production
Industrial machinery and equipment fabrication
Electrical cabinet and enclosure manufacturing
Construction and structural steel processing
General sheet metal cutting and job shops
Why Choose a Dual Pallet Laser Cutting Machine?
Continuous cutting – Material handling and cutting occur simultaneously, eliminating idle time.
Higher throughput – Up to 50–60% increase in productivity compared to single-table systems.
Precision and consistency – High cutting accuracy with smooth, high-quality edges.
Scalable and versatile – Suitable for a wide range of materials, thicknesses, and industries.
Automation-ready – Compatible with loading/unloading systems, conveyors, and robotic arms.
FAQ
Q1: What is the main advantage of a dual pallet laser cutting machine?
A1: The dual pallet design allows one pallet to cut while the other is loaded or unloaded, significantly reducing downtime and improving production efficiency.
Q2: What types of materials can this machine cut?
A2: It can cut a wide range of metals, including carbon steel, stainless steel, aluminum, copper, brass, galvanized steel, and alloy steel.
Q3: What is the maximum thickness it can cut?
A3: This depends on the laser power. For example, a 6000W laser can cut up to 25 mm carbon steel, while a 20kW+ system can cut up to 50 mm.
Q4: Is it suitable for 24/7 industrial production?
A4: Yes. The machine is engineered for continuous, heavy-duty operation and is widely used in high-volume production environments.
Q5: Can I automate the loading and unloading process?
A5: Absolutely. We offer optional automation solutions including robotic arms, conveyor systems, and automatic pallet changers to further improve productivity.
Q6: How much maintenance does the machine require?
A6: Very little. Fiber laser systems have no mirrors, no laser gas, and minimal moving parts, resulting in low maintenance and long service life.
Q7: How long is the typical lifespan of the fiber laser source?
A7: Most fiber laser sources have a service life of 100,000+ hours, ensuring many years of reliable operation.
