Gantry type fiber laser cutting machine for large format sheets
The Gantry Type Fiber Laser Cutting Machine for Large Format Sheets is a heavy-duty industrial solution engineered to handle extra-large metal plates with exceptional speed, accuracy, and reliability.
Brand：Gain
Product origin：Weifang,Shandong,China
Delivery time：7-30 days
Supply capacity：500 units/year
Send Inquiry
Product Description
Gantry Type Fiber Laser Cutting Machine for Large Format Sheets
High-Precision, High-Efficiency Cutting Solution for Oversized Metal Plates
The Gantry Type Fiber Laser Cutting Machine for Large Format Sheets is a heavy-duty industrial solution engineered to handle extra-large metal plates with exceptional speed, accuracy, and reliability. Designed for manufacturers working with large-format materials in industries such as shipbuilding, construction machinery, aerospace, heavy equipment, and steel fabrication, this machine offers the perfect combination of powerful laser technology, stable gantry structure, and intelligent automation.
With a rigid gantry-type design, the machine ensures high structural stability and cutting precision even during long working hours. The advanced fiber laser source delivers clean, burr-free cuts on a wide range of metals, including carbon steel, stainless steel, aluminum, copper, and alloy materials, while significantly reducing operating costs and maintenance requirements.
Key Features
Extra-Large Cutting Area
Capable of processing metal sheets up to 12m x 3m (customizable), ideal for oversized workpieces without repositioning.
Heavy-Duty Gantry Structure
Robust welded steel frame with advanced heat treatment for superior rigidity, vibration resistance, and cutting stability.
High-Power Fiber Laser Source
Available from 6kW to 30kW, offering high-speed cutting performance with excellent edge quality and minimal heat distortion.
Precision Motion System
Imported linear guides, rack and pinion drives, and servo motors ensure cutting accuracy of ±0.03mm and repeatability of ±0.02mm.
Intelligent CNC Control
User-friendly operating software supports nesting, automatic path optimization, and real-time monitoring for maximum productivity.
Wide Material Compatibility
Cuts carbon steel, stainless steel, aluminum, brass, galvanized sheet, and more — even at large thicknesses.
Low Maintenance & Energy Efficient
Fiber laser technology offers long service life, minimal maintenance, and energy savings compared to traditional CO₂ systems.
Technical Specifications
| Parameter | Value |
| Cutting Area | 6000×2500 mm – 12000×3000 mm (customizable) |
| Laser Power | 6kW – 30kW |
| Positioning Accuracy | ±0.03 mm |
| Repeatability | ±0.02 mm |
| Max Cutting Speed | Up to 140 m/min |
| Supported Materials | Carbon steel, stainless steel, aluminum, copper, brass, alloy steel, etc. |
| CNC System | Industrial-grade fiber laser control system with touch screen |
| Cooling System | Water cooling |
| Assist Gas | Oxygen, nitrogen, air |
Applications
Shipbuilding and Marine Engineering
Heavy Machinery Manufacturing
Aerospace and Defense
Large-Scale Steel Structure Fabrication
Industrial Equipment and Construction Machinery
Renewable Energy and Wind Power Components
Why Choose Our Gantry Laser Cutting Machine?
Tailored for oversized sheets – no need for repositioning, saving time and improving efficiency.
Outstanding cutting quality – smooth, burr-free edges with minimal post-processing.
Industrial-grade durability – built for continuous heavy-duty production.
Lower cost per cut – high electrical efficiency and minimal consumables.
Smart operation – intuitive software with remote monitoring and IoT capabilities.
FAQ
Q1: What is the maximum sheet size the machine can cut?
A1: Standard models support up to 12,000mm × 3,000mm, but we can customize the working area based on your production needs.
Q2: Which materials can this laser cutting machine process?
A2: It is suitable for a wide range of metals, including carbon steel, stainless steel, aluminum, copper, brass, and alloy steel — even at large thicknesses.
Q3: What laser power should I choose?
A3: It depends on the thickness and type of material you want to cut. For example, 6kW–12kW is ideal for medium-thickness plates, while 15kW+ is recommended for thick or heavy-duty cutting.
Q4: Is it possible to integrate this machine into a fully automated production line?
A4: Yes. We offer optional automation solutions such as loading/unloading systems, pallet changers, and robotic arms to maximize productivity.
Q5: How is the machine installed and supported internationally?
A5: Our technical team provides on-site installation, training, and after-sales support worldwide, including online remote assistance and spare parts service.
Q6: What is the average lifespan of the fiber laser source?
A6: Fiber laser sources typically last 100,000+ hours with minimal maintenance, offering a long-term, cost-effective cutting solution.
